1. Advanced computerized system control
2. Pneumatically driven adopt from FESTO, can adjust the movement speed of each part
3. Built-in LED digital counter
4. Emergency stop system to ensure the safety of operator
5. Light-weight, strong aluminum cast machine frame
6. Ink trays, work table and pads are independently adjustable for easy color registration
7. Speed, pad and printing stroke are easily adjustable for different printing requirements
8. Ink tray, doctor blade, brush and pads are easily installed and dismounted for quick cleaning
| Model | PADMAC-6P | ||
| 150ST | 200ST | 220ST | |
| Print Color | 6 color | ||
| Work station | 1 pc | ||
| Print Head Stroke | 75mm | 75mm | 75mm |
| Sliding Cylinder Stroke | 175mm | 225mm | 225mm |
| Standard Plate size(mm) | 100 x 150 | 100 x 200 | 165 x 196 |
| Work Table size(mm) | 165 x 165 | 165 x 165 | 150 x 200 |
| Maximum Print Size(mm) | 80 x 130 | 80 x 180 | 130 x 180 |
| Maximum speed(pcs/hr) | 800 | 700 | 500 |
| Power | 220V 50Hz | ||
| Power | 35W | ||
| Pressure | 6 Bar | ||
| Air Consumption(liter/min) | 72 | 78 | 82 |
| Dimensions(mm) | 1000x910x1450 | 1300x910x1450 | 1340x910x1450 |
| Weight(kg) | 190 | 220 | 240 |
